Home ProductsHigh Speed Hydraulic Winch (AF series)

custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch

custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch

China custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch supplier
custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch supplier custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch supplier custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch supplier custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch supplier custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch supplier custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch supplier

Large Image :  custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch

Product Details:

Place of Origin: CHINA
Brand Name: cathyhsu@foxmail.com
Certification: ISO
Model Number: AF series

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: case
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 300 units/month
Contact Now
Detailed Product Description
Used As: Hoisting Hydraulic Winch/marine Winch/dredger Winch Pull Force: 1-100 Ton
Driven By: High Speed Hydraulic Motor Can Be Equipped With: Cable Roller
Contact: Cathyhsu@foxmail.com

China high quality hydraulic winch maufacturer



We are the China-based manufacturer of hydraulic winch (hydraulic winch, hoisting winch, wireline winch, cargo winch, drilling rig winch, crane winch, marine winch, dredger winch, hydraulic winches, compact winch, free fall hydraulic winch) with more than 10 years experience in designing and manufacturing different types of hydraulic winches fro widely application.

Company introduction
We are the group company in China, the registered capacity is 6,000,000 and the factory area is about 6000sqm. Staffed with 150 employees, including 10 engineers.

The products are widely used inengineering machinery, ship-, petroleum-, mining industry, metallurgical machinery, light industry, agriculture, enviroment.

Now we are stepping into the international market, our products are being exported toGermany, USA, CANADA, ITALY, NETHERLAND, KOREAM, SINGAPORE, TURKEY, AUSTRALIA, INDIA, INDONESIA and others.

Introduction of hydraulic winch AF series
custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch
For the winch in the picture, it is our AF series hydraulic winch, which is widely used in ship crane, harbor, petroleum, drill machine, engineering machinery, geological exploration and construction machinery. It is the best choice for those situations which requires large power, high speed and high security.

Special features of winch:
1.Two-or three-stage planetary gearboxes, smooth operation and reasonable structure.
2.Normally closed friction type brake, high braking torque, safe and reliable operating.
3.Small volume, compact structure and high transmission efficiency.
4.Axial fixed or variable hydraulic motor with long life operating.
5.Mounting frame is available on request.
6.Balance valve, shuttle valve, limit switch and other accessories are also available on request.
For the folowing specification in the table, it is for your reference. We can also manufacture the winch with pull force up to 60,000kgs based on your requirements.


Specification of hydraulic winch:

Model Pull Force (KN) Rope Speed (m/min) Diameter of rope (mm) Capacity of rope (m) Working pressures diff. (Mpa) Flow Rate (L/min)
1st layer

top layer

AF5700 5700 4500 60 16 107 25 160
AF7700 7700 6000 52 18 118 25 180
AF9600 9600 7500 43 20 118 25 180
AF12800 12800 9800 43 24 118 27 220
AF15000 15000 12800 39 24 110 25 220
AF18500 18500 14600 85.3 28 162 27 380
AF25000 25000 19500 48.1 30 162 27 380
AF30000 30000 23000 32 32 169 30 380
AF45000 45000 34700 32 42 169 30 380

Note: the above specification of winch are only for your reference. We can also design and manufacture the winch based on your requirements for different applications.



Contact Information:

Contact: Cathy

Skype: kemercathy

Email: cathyhsu@foxmail.com

Tel: 0086-134 8664 5746



Factory overview

hydraulic winchfactory overviewwinch production

custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winchcustom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winchcustom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winchcustom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winchpicture of winch



custom built hydraulic winch hoisting winch drilling rig winch crane winch dredger winch
