custom built 20 ton/200KN marine winch dredger winch

Place of Origin china
Brand Name cathyhsu@foxmail.com
Certification ISO9001
Model Number GW series
Minimum Order Quantity 1 unit
Price Negotiation
Packaging Details case
Delivery Time 3-20 days
Payment Terms T/T or L/C , Western Union
Supply Ability on request
Product Details
Pull Force 20000kgs/200KN/20TON Hydraulic Winch Rope Speed 0-200m/min
Dimension Custom Built Contact Cathy
Skype Kemercathy Email Cathyhsu@foxmail.com
Cell/whatsapp/wechat +8613486645746
Leave a Message
Product Description
china hydraulic winch manufacturer

hydraulic winch hoisting winch marine winch dredger winch 20 ton winch 20 ton marine winch

hydraulic winch manufacturer, hydraulic winches, hoisting winch, marine winch, drilling rig winch, crane winch, power winch, hydraulic operated winch, dredger winch


Company introduction

We are the manufacturer of hydraulic winch from Ningbo, China.



We have more than 20 years' experiences in designing and manufacturing different kinds of hydraulic winch for widely application.



Production procedure: designing the drawing-confirmation by customer-production



For the hydraulic winch, it is the custom product. Each customer has different requirements for the pull force, rope speed, rope diameter, drum capacity and dimension of hydraulic winch. We have experienced engineering tems who can offer special design for each application.



How to get suitable hydraulic winch?

To make sure the winch we offered is suitable for your application, please offer:

1. pull force of inner layer (kg):

2. rope speed of inner layer (m/min):

3. rope diameter (mm):

4. length of rope (m):

5. drum diameter (mm):

6. with or without groove:

7. with or without brake:



For more, please send inquiry to:

Cathy Hsu

Sales manager

Email: cathyhsu@foxmail.com

Skype: kemercathy

Whatsapp/wechat/tel: +86 134 8664 5746


Product introduction

For the winch in the picture, it is our GW series hydraulic winches (hydraulic winch, hoisting winch, wireline winch, drilling rig winch, crane winch, dredger winch), which are widely used in marine deck machinery, harbor, petroleum, drill machine, engineering machinery, mining, geological exploration and construction machinery.

hydraulic winch hoisting winch marin winch crane winch dredger winch

Features:


1. One-or two-stage planetary gearboxes, smooth operation and reasonable structure.
2. Normally closed friction type brake, high braking torque, safe and reliable operating.
3. Small volume, compact structure and high transmission efficiency.
4. Radial piston hydraulic motor with long life operating.
5. Mounting frame is available on request.
6. Balance valve, shuttle valve, limit switch and other accessories are also available on request.



Specification:


For the following specification, it is for your reference, we can also design and manufacture the winch with pull force up to 60 ton based on your requirements.



Type Inner layer displacement (ml/r) Hoitsting pressure (Mpa) Flow rate (L) Rope diameter (mm) Rope capacity(m) motor Gearbox type
Pull force (KN)

Rope speed

(m/min)

GWI3-10-122-10-ZP 10 54 859.5 14.3 56 10 122 GN05-170 C3
GWI3-15-122-10-ZP 15 55 859.5 21.5 56 10 122 GN05-170 C3
GWI3-20-66-14-ZP 20 43 1146 21.5 56 14 66 GN05-200 C3
GWI2.53-25-165-14-ZP 25 33 1634 19.8 60 14 165 GN05-90 C2.53
GWI2.53-30-165-14-ZP 30 25 2185 17.8 60 14 165 GN05-110 C2.53
GWI2.53-40-149-16-ZP 40 26 2451 21.3 70 16 149 GN05-130 C2.53
GWI2.53-50-149-16-ZP 50 23 3154 20.7 80 16 149 GN05-170 C2.53
GWI2.53-60-149-16-ZP 60 21 3629 21.6 80 16 149 GN05-200 C2.53
GWI34-60-160-18-ZP 60 14 5775 16.6 70 18 160 GN1-150 C34
GWI34-70-160-18-ZP 70 13 6450 17.3 70 18 160 GN1-175 C34
GWI34-80-90-24-ZP 80 14 7537.5 17.2 90 24 90 GN1-200 C34
GWI34-90-90-24-ZP 90 12 9112.5 16 90 24 90 GN1-250 C34
GWI34-100-90-24-ZP 100 12 9112.5 17.8 90 24 90 GN1-250 C34
GWI45-90-169-24-ZP 90 15 11400 16.5 110 24 169 GN2-300 C45
GWI45-100-169-24-ZP 100 15 11400 18.3 110 24 169 GN2-300 C45
GWI45-110-154-26-ZP 110 14 13012.5 17.7 120 26 154 GN2-350 C45
GWI45-120-149-28-ZP 120 14 13012.5 19.3 120 28 149 GN2-350 C45
GWI66-140-267-30-ZP 140 25 19826.8 18 258 30 267 GN4-1000 C66
GWI66-160-253-32-ZP 160 23 21650.4 18.6 258 32 253 GN4-1100 C66
GWI66-180-229-36-ZP 180 20 24191.4 18.8 258 36 229 GN4-1250 C66
GWI66-200-229-36-ZP 200 20 25530.4 19.8 258 36 229 GN4-1300 C66



Picture for reference:

hydraulic winch hoisting winch marine winchcustom built 20 ton/200KN marine winch dredger winch 3hydraulic winch hoisting winch marine winch dredger winch

custom built 20 ton/200KN marine winch dredger winch 5

custom built 20 ton/200KN marine winch dredger winch 6



Factory overview

custom built 20 ton/200KN marine winch dredger winch 7custom built 20 ton/200KN marine winch dredger winch 8custom built 20 ton/200KN marine winch dredger winch 9

Package


high quality radial piston hydraulic motor (GM series)
