custom built 303L 305L planetary gearbox from China factory

Place of Origin: China
Brand Name: cathyhsu@foxmail.com
Certification: ISO9001
Model Number: BL300 series
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: case
Delivery Time: 10-30 days
Payment Terms: T/T, L/C
Supply Ability: ON REQUEST
Product Details
Output Torque: 1000-450000N.m Gearing Arrangement: Planetary Gearbox
Leave a Message
Product Description

China planetary gearbox manufacturer speed reducer

china planetary gearbox supplier



china planetary gearbox factory



offer custom built planetary gearbox

reduction gearbox manufacturer




Ratio

3.4-5000

Output Torque

1000-450000N.m



planetary gearbox rotary head gearbox swing drive gearbox bonfiglioli gearbox

 Features


1. Gear Unit Version:

in line or right angle (with screw bevel pair Gleason)
2. Output Configuration:

Foot and flange mounted
3. Output shaft:

solid with key, splined, splined hollow, hollow shaft with shrink disc
4. Gear Unit Input Configurations:

IEC-normalized Motor Adaptors or Solid Input Shaft
5. Main Brake Motor Features:

DC and AC brake
Hydraulic Brake:

Fast Braking and/or brake releasing through
6. Mounting dimension is available on request.
7. Brake, balance valve, shuttle valve and the distributor which can integrate all kinds of function valve are also available on request.



Technique parameter:

Type

Rated torque

(Nm)

Rated power

(Kw)

Input speed

(Max rpm)

Ratio range for Inline gear

Ratio range for Right angle gear

Ratio range for Combined withworm gear

Design

BL300

1000

20

3000

3.3-2700

7-800

400-9000

A

BL301

1750

30

3000

3.3-2700

7-800

400-9000

A

BL303

2500

40

3000

3.6-2900

9-900

400-9000

A

BL305

5000

60

3000

3.6-2900

9-900

400-9000

A

BL306

8500

75

2500

3.7-2900

9-900

400-9000

A

BL307

12500

100

2500

3.4-2500

13-800

400-9000

A

BL309

18500

130

2500

3.4-2500

13-800

400-9000

B

BL310

25000

150

2000

3.8-2500

40-900

400-9000

B

BL311

35000

180

2000

4-2200

18-800

400-9000

B

BL313

50000

200

2000

4-2200

18-800

400-9000

B

BL315

80000

250

1500

4-2000

70-900

400-9000

B

BL316

105000

270

1500

4-2000

50-600

400-9000

B

BL317

150000

300

1000

4-1900

70-900

400-3000

B

BL318

200000

340

1000

4-1100

200-700

400-9000

B

BL319

300000

380

500

4-1400

300-800

1000-9000

B

BL321

450000

450

500

4-1100

300-800

1000-9000

B

Meanwhile, we can also design and manufacture planetary gearbox according to your requirements.


Contact details:

Cathy Hsu

Email: cathyhsu@foxmail.com

Skype: kemercathy

TEL/WHATSAPP: +8613486645746


Spare part of gearbox

custom built 303L 305L planetary gearbox from China factory 1

Product Picture for reference
