1 ton/2 ton/3 ton/5 ton/6 ton hydraulic winch price
| Place of Origin | Ningbo, China |
|---|---|
| Brand Name | cathyhsu@foxmail.com |
| Certification | ISO9001 |
| Model Number | BG series hydraulic winch |
| Minimum Order Quantity | 1 unit |
| Price | contact me |
| Packaging Details | plywood case without fumigation |
| Delivery Time | 20 days |
| Payment Terms | L/C, T/T |
| Supply Ability | on request |
Product Details
| Application | Hoisting Hydraulic Winch | Applied For | Crane, Drilling Rig, Dredger, Boat, Aerial Platform, Etc. |
|---|---|---|---|
| Pull Force Of Winch | 1 Ton/2 Ton/3 Ton/5 Ton/6 Ton |
Product Description
Manufacturer of hydraulic winch
China hydraulic winch supplier
hydraulic winch manufacturer
1 ton/2 ton/3 ton/5 ton/6 ton hydraulic winch price
We are the China-based manufacturer of hydraulic winch (hydraulic winch, hoisting winch, wireline winch, cargo winch, drilling rig winch, crane winch, marine winch, dredger winch, hydraulic winches, compact winch, free fall hydraulic winch) with more than 10 years experience in designing and manufacturing different types of hydraulic winches fro widely application.
We are the group company in China, the registered capacity is 6,000,000 and the factory area is about 6000sqm. Staffed with 150 employees, including 10 engineers.
The products are widely used inengineering machinery, ship-, petroleum-, mining industry, metallurgical machinery, light industry, agriculture, enviroment.
Now we are stepping into the international market, our products are being exported toGermany, USA, CANADA, ITALY, NETHERLAND, KOREAM, SINGAPORE, TURKEY, AUSTRALIA, INDIA, INDONESIA and others.
This type of hydraulic winch is mainly composed of hydraulic motor , brake, gear box, drum, support shaft, frame, rope device (optional), etc.
Our whiches can be widely used in all kinds of lifting equipment, such as railway locomotive and truck crane, ship, oil field drilling, coal mine, port, small engineering machinery and so on.
For the following specification, it is for your reference, we can also design and manufacture the winch with pull force up to 60 ton based on your requirements.
| Model | Pull Force (KN) | Rope Speed (m/min) | Diameter of rope (mm) | Capacity of rope (m) | Working pressures diff. (Mpa) | Flow Rate (L/min) | |
| 1st layer | top layer | ||||||
| BG500 | 500 | 380 | 63 | 6 | 67 | 14 | 40 |
| BG800 | 800 | 680 | 54 | 8 | 53 | 14 | 50 |
| BG1100 | 1100 | 870 | 41 | 8 | 53 | 14 | 50 |
| BG1300 | 1300 | 1000 | 45 | 9 | 48 | 14 | 55 |
| BG1500 | 1500 | 1200 | 42 | 10 | 60 | 21 | 55 |
| BG2000 | 2000 | 1600 | 35 | 10 | 60 | 21 | 55 |
| BG2500 | 2500 | 2000 | 52 | 12 | 52 | 21 | 100 |
| BG2600 | 2600 | 2000 | 54 | 12 | 76 | 21 |
100 |
Product details:
