Rexroth Planetary Gearbox Gft17/Gft26/Gft34/Gft36/Gft40/Gft50

Place of Origin Ningbo
Brand Name cathyhsu@foxmail.com
Certification ISO9001
Model Number GFT series
Minimum Order Quantity 1 unit
Price Negotiation
Packaging Details case
Delivery Time 3-20 days
Payment Terms T/T or L/C
Supply Ability on request
Product Details
Material Planetary Gearbox For Track Drive Application Replace Rexroth GFT07/10/17/24/26/40/45/50/60/80/110/160/220/330/450 Series Planetary Gearbox
Torque 1000-450000Nm Gearing Arrangement Planetary
Warranty 1 Year Quality 100%tested
Condition New
Leave a Message
Product Description

china planetary gearbox manufacturer

China track drive gearbox manufacturer

interchanged with Rexroth GFT travel drive gearbox on performance and dimensions




Applied as track drive gearbox, wheel drive gearbox, winch drive gearbox



Replace Rexroth GFT series travel drive gearbox



Model: GFT13T2, GFT17T2, GFT17T3, GFT24T3, GFT26T2, GFT34T3, GFT36T3, GFT40T3, GFT50T3, GFT60T3, GFT80T3, GFT110T3, GFT160T3, GFT220T3, GFT330T3, GFT450T3





rexroth GFT series track drive gearbox Rexroth GFT series Travel Drive Track Motor Track Drive Final Drive Rexroth GFT series final drive GFT17, GFT24, GFT26, GFT34, GFT36, GFT40, GFT50, GFT60, GFT80, GFT110, GFT160, GFT220, GFT330



Our factory mass produced Rexroth GFT series compact high speed travel drive from GFT 13T2 to GFT 330T3 (13000-330000 N.m)



As a trustworthy manufacturer and supplier, we have a dominating market sharein China, and we also enjoy an increasing market share worldwide.Our products have been exported to:

-Europe: UK, Austria,Netherlands, Germany, Sweden
-North America: USA, Canada
-South America: Brazil, Argentina
-Russia, Australia,Turkey, Southeast Asia, Middle East, India, Korea and othercountries in the world.



We can make special ratios for customers exceptfor standard ratios of Rexroth GFT series gearboxes.




Overview

Interchanged with Rexroth GFT track drive gearbox Rexroth GFT series Travel Drive Track Motor Track Drive Final Drive gearbox  Model: GFT13T2, GFT17T2, GFT17T3, GFT24T3, GFT26T2, GFT36T3, GFT50T3, GFT60T3, GFT80T3, GFT110T3, GFT160T3, GFT220T3
HYDROTRAC GFT is an ideal driving component for wheel or track driving vehicles, and other moving equipment and widely applied in excavator, spreading machine, drill machine, mobile crusher, engineering machinery, mining, tunnel machinery, agricultural machinery, etc. Meanwhile, different motor connectors and dimensions are available on request. It is an ideal replacement of Rexroth products.


Special Features:

1. Compact two-, three- or four-stage planetary gearboxes
2. Cageless planetary gear bearing
3. Robust main bearing
4. Optimized seals
5. Integr. multi-disc parking brake
6. Optional for mounting Rexroth fixed or variable motors (A2FM/E, A6VM/E, A10VM/E)
7. Interchangeable with Rexroth on performance and dimension.
8. More than 80% components can be interchanged with those of Rexroth (planet gear, Cageless planetary gear bearing, planet carrier, ring gear and so on).



GFT13T2, GFT17T2, GFT17T3, GFT24T3, GFT26T2, GFT36T3, GFT50T3, GFT60T3, GFT80T3, GFT110T3, GFT160T3, GFT220T3, GFT330T3,

Type / Model

GFT 7 T2

GFT 9 T2

GFT 13 T2

GFT 17 T2

GFT 17 T3

GFT 24 T3

Output torque(Nm)

7000

9000

13000

17000

17000

24000

Ratio(i)

17 - 39

21- 80

23 - 60

28 - 54

70 - 220

63 - 137

Hydraulic motor

Eaton SAE Motor

A2FE32

A2FE56

A2FE63

A2FE56

A2FE63

A6VE55

A6VE55

A6VE55

A6VE55

Weight(kg)

52

77

106

104

121

132



Type / Model

GFT 26 T2

GFT 36 T3

GFT 40 T2

GFT 50 T3

GFT 60 T3

GFT 80 T3

Output torque(Nm)

26000

36000

40000

50000

60000

80000

Ratio(i)

38 - 62

63 - 136

36 - 60

62 - 176

86- 172

78 - 186

Hydraulic motor

A2FE90

A2FE90

A2FE125

A2FE125

A2FE125

A2FE180

A6VE80

A6VE80

A6VE160

A6VE107

A6VE107

A6VE160

Weight(kg)

178

196

247

253

299

466



Type / Model

GFT 110 T3

GFT 160 T3

GFT 220 T3

GFT 330 T3

Output torque(Nm)

110000

160000

220000

330000

Ratio(i)

80 - 215

162 - 251

98 - 293

169 - 303

Hydraulic motor

A2FE180

A2FE180

A2FE180

A2FE355

A6VE160

A6VE160

A6VE160

A6VE250

Weight(kg)

581

782

1576

1438



Welcome to contact us:

Contact Cathy

Please send mail to Email: cathyhsu@foxmail.com

Tel/whatsapp/wechat: +86 134 8664 5746


How to order:

1. do you require track drive gearbox, winch drive gearbox or wheel drive gearbox:

2. ratio of gearbox:

3. with or without brake:

4. model of motor:

5. for new design or replacement of old gearbox:




Product picture for reference

rexroth gearbox GFT gearbox planetary gearbox track drive gearbox winch drive gearbox wheel drive gearbox GFTGFT7T2      GFT9T2      GFT13T2        GFT17T2      GFT17T3  GFT24T3     GFT26T3     GFT36T3        GFT50T3      GFT60T2  GFT60T3     GFT80T2     GFT80T3        GFT110T3     GFT160T3  GFT220T3    GFT330T3 PLANETARY GEARBOX rexroth gearbox track drive gearbox winch drive gearbox wheek drive gearboxGFT7T2      GFT9T2      GFT13T2        GFT17T2      GFT17T3  GFT24T3     GFT26T3     GFT36T3        GFT50T3      GFT60T2  GFT60T3     GFT80T2     GFT80T3        GFT110T3     GFT160T3  GFT220T3    GFT330T3 PLANETARY GEARBOX rexroth gearbox track drive gearbox winch drive gearbox wheek drive gearboxRexroth Planetary Gearbox Gft17/Gft26/Gft34/Gft36/Gft40/Gft50 4
