custom designed hoisting hydraulic winch for marine application from China

Place of Origin china
Brand Name kemercn@hotmail.com
Certification ISO9001
Model Number GW series
Minimum Order Quantity 1 SET
Price Negotiation
Packaging Details case
Delivery Time 3-20 days
Payment Terms T/T or L/C
Supply Ability on request

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Pull Force 500-60,000kgs Rope Speed 0-200m/min
Dimension Custom Built Contact Cathy
Skype Kemercathy Email Kemercn@hotmail.com; Cathyhsu@foxmail.com
Whatsapp +8613486645746 Application Cranes,petroleum,drill Machine,drill Rig,harbor
Capacity 1000 - 100000kgs Power Source Hydraulic
Material Steel Product Name Hydraulic Winch
Leave a Message
Product Description
China hydraulic winch manufacturer

Get hydraulic winch from china factory directly

hydraulic winch manufacturer, hydraulic winches, hoisting winch, marine winch, drilling rig winch, crane winch, power winch, hydraulic operated winch, dredger winch
hydraulic winch hoisting winch marine winch boat winch dredger winch crane winch

We are the manufacturer of hydraulic winch from Ningbo, China.



We have more than 20 years' experiences in designing and manufacturing different kinds of hydraulic winch for widely application.



Production procedure: designing the drawing-confirmation by customer-production



For the hydraulic winch, it is the custom product. Each customer has different requirements for the pull force, rope speed, rope diameter, drum capacity and dimension of hydraulic winch. We have experienced engineering tems who can offer special design for each application.



How to get suitable hydraulic winch?

To make sure the winch we offered is suitable for your application, please offer:

1. pull force of inner layer (kg):

2. rope speed of inner layer (m/min):

3. rope diameter (mm):

4. length of rope (m):

5. drum diameter (mm):

6. with or without groove:

7. with or without brake:



For more, please send inquiry to:

Cathy Hsu

Sales manager

Email: cathyhsu@foxmail.com

Skype: kemercathy

Whatsapp/wechat/tel: +86 134 8664 5746





Here what we describe is our GW series hydraulic winch which is driven by radial piston hydraulic motor.



Product description

We are the China-based manufacturer of hydraulic winch (hydraulic winch, hoisting winch, wireline winch, cargo winch, drilling rig winch, crane winch, marine winch, dredger winch, hydraulic winches, compact winch, free fall hydraulic winch) with more than 10 years experience in designing and manufacturing different types of hydraulic winches fro widely application.

We are the group company in China, the registered capacity is 6,000,000 and the factory area is about 6000sqm. Staffed with 150 employees, including 10 engineers.

The products are widely used in engineering machinery, ship-, petroleum-, mining industry, metallurgical machinery, light industry, agriculture, enviroment.

Now we are stepping into the international market, our products are being exported to Germany, USA, CANADA, ITALY, NETHERLAND, KOREAM, SINGAPORE, TURKEY, AUSTRALIA, INDIA, INDONESIA and others.

Description of hydraulic winch AF series

For the winch in the picture, it is our GW series hydraulic winch, it can be made as single drum winch, double drum hydraulic winch, free fall hydraulic winch. GW series hydraulic winches are widely used in marine deck machinery, harbor, petroleum, drill machine, engineering machinery, mining, geological exploration and construction machinery.

Special Features:

♦ One-or two-stage planetary gearboxes, smooth operation and reasonable structure.
♦ Normally closed friction type brake, high braking torque, safe and reliable operating.
♦ Small volume, compact structure and high transmission efficiency.
♦ Radial piston hydraulic motor with long life operating.
♦ Mounting frame is available on request.
♦ Balance valve, shuttle valve, limit switch and other accessories are also available on request


Specification


For the folowing specification in the table, it is for your reference. We can also manufacture the winch with pull force up to 60,000kgs based on your requirements.


Model W.L.L.
1st layer
W.L.L.
top layer
Rope
Speed
Rope
diam.
Capacity of
Rope
Working
Pressure
Max Supply
Oil Flow

  kgf kgf m/min mm m Mpa L/min

GW1000 1000 860 30 10 60 16 40
GW2000 2000 1680 30 12 50 16 70
GW3000 3000 2526 35 15 65 16 80
GW4000 4000 3335 35 16 65 17 100
GW5000 5000 4167 40 20 87 16 160
GW6000 6000 4922 40 21.5 68 16 190
GW8000 8000 6698 40 24 100 16 260
GW10000 10000 7846 40 28 90 16 310
GW12000 12000 10080 30 30 175 17 270
GW15000 15000 9880 25 34 150 20 240
GW18000 18000 14700 30 38 143 18 360





Custom service


The above specification is just for your reference. We can also design and manufacture the hydraulic winch based on your detail requirements.





Detail of hydraulic winch


hydraulic winch hoisting winch marine winch dredger winch industrial winch ladder winch cargo winch swing winch drilling rig winch crane winch hydraulic winch hoisting winch marine winch dredger winch industrial winch ladder winch cargo winch swing winch drilling rig winch crane winch custom designed hoisting hydraulic winch for marine application from China 3

Company overview


custom designed hoisting hydraulic winch for marine application from China 4hydraulic winch hoisting winch marine winch dredger winch industrial winch ladder winch cargo winch swing winch drilling rig winch crane winch hydraulic winch hoisting winch marine winch dredger winch industrial winch ladder winch cargo winch swing winch drilling rig winch crane winch hydraulic winch hoisting winch marine winch dredger winch industrial winch ladder winch cargo winch swing winch drilling rig winch crane winch

Application of hydraulic winch






Our hydraulic winches can be widely used in conveyor tensioning device and mechanical engineering from heavy machinery such as truck crane, crawler crane, aerial vehicles, forestry crane, and shipping ports such as port cranes, floating crane, dredger, cranes, davits, and can for large play equipment such as oil rigs and offshore oil drilling platform, piling machinery rotary drilling rig, drilling, core drilling, hydrostatic pressure pile machine and so on.

custom designed hoisting hydraulic winch for marine application from China 8



FAQ

Q: Are you trading company or manufacturer ?

A: We are factory of hydraulic winch.

Q: How long is your delivery time?

A: Generally it is 15-35 days if the goods is the standard dimension.

Q: Can you custom make the product?

A: Yes, all dimensions and specifications of hydraulic winch can be designed and made based on your requirements.

Q: How to order?

A: To make sure the offered hydraulic winch is suitable for your application, please offer the following details:
1. pull force of inner layer (kg):
2. rope speed of inner layer (m/min):
3. rope diameter (mm):
4. length of rope (m):
5. drum diameter (mm):
6. with or without groove:
7. with or without brake:
If you have another question about the hydraulic winch, pls feel free to contact us.
