custom built high quality steel track undercarriage (crawler undercarriage)

Place of Origin	Ningbo
Brand Name	kemercn@hotmail.com
Certification	ISO9001
Model Number	KST series
Minimum Order Quantity	1 set
Price	Negotiation
Packaging Details	pallet
Delivery Time	3-20 days
Payment Terms	T/T or L/C
Supply Ability	on request

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Type	Steel Track Undercarriage	Load Capacity	0.5-100 Ton
Travelling Speed	0-10Km/hr

Leave a Message

Product Description

Steel Track undercarriage manufacturer

Steel track undercarriage, Steel track frame, steel track chassis, steel track system, steel crawlerundercarriage, steel tracked undercarriage, drilling rig steel track undercarriage, crusher steel track undercarriage, excavator track undercarriage

We are an experienced company specialized in manufacturing steel track undercarriage and rubber track undercarriage. we make custom track systems for your mobility needs, and our track undercarriage can carry up to 50ton,and supporting dual-speed final drive and travel 0-7km/h at grades up to 60%.

Specification of track undercarriage:

1.Load capacity: 500kgs-50,000kgs

2.walking speed: 0-10km/hr

3.travel drive: dual speed final drive or single speed, Rexroth GFT gearbox

6.delivery time: 3-20 days

7.Custom built: we can design and manufacture track undercarriage according to your specificdimension requirements.

Kemeris an experienced company specialized in manufacturing steel track undercarriage and rubber trackundercarriage. We make custom track systems for your mobility needs, and our track undercarriage cancarry up to 50ton, and supporting dual-speed final drive and travel 0-7km/h at grades up to 100%.

Application

Special design catered to customer specifications. With years of experience we can offer the track designflexibility, rapid response and solutions that are always highly effective.

For application on drilling rigs, excavators, crushers, cranes, aerial platform, etc. with high efficiency andadaption of vile working condition.

Customize Solution

We have many professional engineers devoting to design the track undercarriages to meet differentcustomers' requirements. With our years of experience, we can take your concept from prototype toproduction. We are committed to our goal of exceeding your expectations and requirements for quality,reliability, and on-time delivery.

Specification

For the following dimension and specification, it is just for your reference, we can also design andmanufacture the winch based on your requirements.ST-STEEL TRACK UNDERCARRIAGE

MODEL	Dinamic capacity	Static capacity	Weight kg.	Press.Bar	oil flow L/min	Torque Nm to engine	Grad.	Speed km/h
ST-3500	3500	4000	750	220	35	4723	65%	2/3.2
ST-6000	6000	7000	1350	220	55	8330	65%	2/3.7
ST-8000	8000	9500	1830	300	82	11700	65%	2.8/4.7
ST-10000	10000	11300	2350	350	100	14800	65%	3/5.1
ST-12000	12000	15000	2950	350	124	22500	65%	2.9/4.9
ST-15000	15000	18000	3300	350	140	24000	65%	3.2/5.5
ST-20000	20000	25000	4300	350	220	38000	65%	3.5/5.4
ST-30000	30000	37000	6500	330	260	59000	65%	2.5/4.6
ST-40000	40000	480000	7100	350	290	72800	65%	2.3/4.3

MODEL	A Length	B Center Distance	C Height	D Total Width	E Width of track shoe	F Height of Cross beam	No. of roller
ST-3500	2030	1500	485	1800	300	225	4+4
ST-6000	2467	1950	549	1700	300-400	240	5+5
ST-8000	2783	2265	548	1800	400-450	255	8+8
ST-10000	3800	3200	600	1700	400-500	280	9+9
ST-12000	3282	2575	720	2000	400-600	345	9+9
ST-15000	3666	2923	753	2000	500-800	360	8+8
ST-20000	4065	3323	786		500-800	375	8+8
ST-30000	4530	3730	836		500-800	405	9+9
ST-40000	4888	4090	880		500-800	420	10+10

Picture of undercarriage for reference

custom built high quality steel track undercarriage (crawler undercarriage) 1

Factory Overview

custom built high quality steel track undercarriage (crawler undercarriage) 4

FAQ

1. Are you the manufacturer or trader?

We are the manufacturer with more than 20 years experience engaged in designing and manufacturing of undercarriage.

2. How long is the delivery?

Usually it is 20 days for the production.

3. What's the warranty of your product?

We can offer you 12 months quality guarantee period after receipt of product.

4. Can you custom make the product?

Yes, all dimensions and specifications can be designed and made based on your requirements.

5. How to order?

To make sure the offered undercarriage is suitable for your application, please offer the following details:

1. Rubber or steel track undercarriage:

2. What is the payload of undercarriage:

Note: it is the weight of machine excluding the weight of undercarriage.

3. length of track undercarriage (mm):

4. width of each side of track undercarriage (mm):

5. height of track undercarriage (mm):

6. total width of track undercarriage (mm):
7. working flow rate per each side of undercarriage (L/min):
8. working pressure (MPa):

9. travelling speed (km/hr):

10. climbing capacity:
