Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox

Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox

China Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier
Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox supplier

Large Image :  Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox

Product Details:

Place of Origin: Ningbo
Brand Name: cathyhsu@foxmail.com
Certification: ISO9001
Model Number: GFT330T3 series

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: case
Delivery Time: 3-20 days
Payment Terms: T/T or L/C
Supply Ability: on request
Contact: Cathy
Email: cathyhsu@foxmail.com
Skype: kemercathy
Cell: 008613486645746
Contact Now
Detailed Product Description

Planetary gearbox with output torque 330000Nm



Interchanged with Rexroth GFT330T2, GFT330T3 track drive gearbox final drive gearbox travel drive gearbox



Our factory mass produced Rexroth GFT series compact high speed travel drive from GFT 13T2 to GFT 330T3 (13000-330000 N.m)



GFT13T2, GFT17T2, GFT17T3, GFT24T3, GFT26T2, GFT36T3, GFT50T3, GFT60T3, GFT80T3, GFT110T3, GFT160T3, GFT220T3 rexroth planetary gearbox track drive gearbox final drive gearbox wheel drive gearbox winch drive gearbox rexroth gearbox


Overview


HYDROTRAC GFT is an ideal driving component for wheel or track driving vehicles, and other moving equipment and widely applied in excavator, spreading machine, drill machine, mobile crusher, engineering machinery, mining, tunnel machinery, agricultural machinery, etc. Meanwhile, different motor connectors and dimensions are available on request. It is an ideal replacement of Rexroth products.


Special Features:
1. Compact two-, three- or four-stage planetary gearboxes
2. Cageless planetary gear bearing
3. Robust main bearing
4. Optimized seals
5. Integr. multi-disc parking brake
6. Optional for mounting Rexroth fixed or variable motors (A2FM/E, A6VM/E, A10VM/E)
7. Interchangeable with Rexroth on performance and dimension.
8. More than 80% components can be interchanged with those of Rexroth (planet gear, Cageless planetary gear bearing, planet carrier, ring gear and so on).

Technical parameters
Planetary gearbox GFT330T2 GFT330T3 series track drive gearbox












Type/Version GFT 7 T2 GFT 9 T2 GFT 13 T2 GFT 17 T2 GFT 17 T3 GFT 24 T3
Output Torque T2
Max
Nm 7000 9000 13000 17000 17000 24000
Ratio   I 30.9-62.6 38.3-47.6 16.3-60.2 6.4-54 78-102.6 90.1-137.2
Hydraulic Motor     A10VM45 A10VE45 A2FE56
A6VE55
A10VE63
A10VM45
A2FE63
A6VE55
A2FE56
A6VE55
A2FE63
A10VE45
Weight without Motor (approx.)   kg 45 67 92 90 105 115
Type/Version     GFT 26 T3 GFT 36 T3 GFT 50 T3 GFT 60 T2 GFT 60 T3 GFT 80 T2
Output Torque T2
Max
Nm 26000 36000 50000 60000 60000 80000
Ratio   I 42.9-62 67-161 66.3-146.4 23 94.8-197 55.5
Hydraulic Motor     A2FE90
A6VE80
A2FE90
A10VE80
A2FE125
A6VE107
A6VM220 A2VE125
A6VE107
A6VM220
Weight without Motor (approx.)   kg 155 170 220 205 260 570
Type/Version     GFT 80 T3 GFT 110 T3 GFT 160 T3 GFT 220 T3 GFT 330 T3
Output Torque, crane T2
Max
Nm 8000 110000 160000 220000 330000
Ratio   I 76.7-185.4 95.8-215 161.8-251 97.7-365 168.9-302.4
Hydraulic Motor     A2FE180
A6VE160
A2FE180
A6VE160
A2FE180
A6VE160
A2FE180
A6VE160
A6VM355
A2FE355
A6VE250

Weight without Motor (approx.)   kg 405 505 680 1370 1250







Product picture for reference Planetary gearbox GFT330T2 GFT330T3 series track drive gearboxPlanetary gearbox GFT330T2 GFT330T3 series track drive gearboxPlanetary gearbox GFT330T2 GFT330T3 series track drive gearboxPlanetary gearbox GFT330T2 GFT330T3 series track drive gearboxGFT7T2      GFT9T2      GFT13T2        GFT17T2      GFT17T3  GFT24T3     GFT26T3     GFT36T3        GFT50T3      GFT60T2  GFT60T3     GFT80T2     GFT80T3        GFT110T3     GFT160T3  GFT220T3    GFT330T3 PLANETARY GEARBOX rexroth gearbox track drive gearbox winch drive gearbox wheek drive gearboxGFT7T2      GFT9T2      GFT13T2        GFT17T2      GFT17T3  GFT24T3     GFT26T3     GFT36T3        GFT50T3      GFT60T2  GFT60T3     GFT80T2     GFT80T3        GFT110T3     GFT160T3  GFT220T3    GFT330T3 PLANETARY GEARBOX rexroth gearbox track drive gearbox winch drive gearbox wheek drive gearboxGFT7T2      GFT9T2      GFT13T2        GFT17T2      GFT17T3  GFT24T3     GFT26T3     GFT36T3        GFT50T3      GFT60T2  GFT60T3     GFT80T2     GFT80T3        GFT110T3     GFT160T3  GFT220T3    GFT330T3 PLANETARY GEARBOX rexroth gearbox track drive gearbox winch drive gearbox wheek drive gearbox
