Product Details:

Place of Origin: china
Brand Name: cathyhsu@foxmail.com
Certification: ISO9001
Model Number: GH series

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: case
Delivery Time: 3-20 days
Payment Terms: T/T or L/C
Supply Ability: on request
Minimum Order Quantity: 1
Contact Now
Detailed Product Description
Pull Force: 500-60,000kgs Rope Speed: 0-200m/min
Dimension: Custom Built Contact: Cathy
Skype: Kemercathy Email: Cathyhsu@foxmail.com
Tel/whatsapp: +8613486645746

hydraulic winch manufacturer



Get hydraulic winch directly from China factory

hydraulic winch hoisting winch marine winch dredger winch ladder winch cargo winch swing winch industrial winch


We are the manufacturer of hydraulic winch from Ningbo, China.



We have more than 20 years' experiences in designing and manufacturing different kinds of hydraulic winch for widely application.



Production procedure: designing the drawing-confirmation by customer-production



For the hydraulic winch, it is the custom product. Each customer has different requirements for the pull force, rope speed, rope diameter, drum capacity and dimension of hydraulic winch. We have experienced engineering tems who can offer special design for each application.



How to get suitable hydraulic winch?

To make sure the winch we offered is suitable for your application, please offer:

1. pull force of inner layer (kg):

2. rope speed of inner layer (m/min):

3. rope diameter (mm):

4. length of rope (m):

5. drum diameter (mm):

6. with or without groove:

7. with or without brake:



For more, please send inquiry to:

Cathy Hsu

Sales manager

Email: cathyhsu@foxmail.com

Skype: kemercathy

Whatsapp/wechat/tel: +86 134 8664 5746





Here what we describe is our GH series hydraulic winch which is driven by RADIAL PISTON hydraulic motor.


hydraulic winch manufacturer, hydraulic winches, hoisting winch, marine winch, drilling rig winch, crane winch, power winch, hydraulic operated winch, dredger winch



For the winch in the picture, it is our GH series hydraulic winches (hydraulic winch, hoisting winch, wireline winch, drilling rig winch, crane winch, dredger winch), which are widely used in marine deck machinery, harbor, petroleum, drill machine, engineering machinery, mining, geological exploration and construction machinery.



Features:
1. One-or two-stage planetary gearboxes, smooth operation and reasonable structure.
2. Normally closed friction type brake, high braking torque, safe and reliable operating.
3. Small volume, compact structure and high transmission efficiency.
4. Radial piston hydraulic motor with long life operating.
5. Mounting frame is available on request.
6. Balance valve, shuttle valve, limit switch and other accessories are also available on request.



For the following specification, it is for your reference, we can also design and manufacture the winch with pull force up to 60 ton based on your requirements.
Model
W.L.L.
1st layer
W.L.L.
top layer
Rope
Speed
Rope
diam.
Capacity of
Rope
Working
Pressure
Max Supply
Oil Flow

kgf
kgf
m/min
mm
m
Mpa
L/min
GH1000
1000
860
25
10
60
15
25
GH2000
2000
1700
25
12
50
14
50
GH3000
3000
2500
35
15
65
16
95
GH4000
4000
3300
35
16
65
14
125
GH5000
5000
4200
40
20
87
14
175
GH6000
6000
4900
40
21.5
68
14
215
GH8000
8000
6700
40
24
100
14
270
GH10000
10000
7800
40
28
90
13
380
GH12000
12000
10000
30
30
176
17
270
GH15000
15000
12000
30
34
153
18
320
GH18000
18000
15000
30
38
143
18
375
GH20000
20000
16000
32
40
150
18
440
GH24000
24000
19000
32
42
140
17
480
GH25000
25000
20000
14
42
110
14
360
GH28000
28000
23000
14
44
105
14
380
GH30000
30000
25000
16
44
155
18
370
GH35000
35000
29000
16
46
150
18
390
GH40000
40000
33000
16
48
145
18
440
