Home ProductsAF series Hydraulic Winch

custom built high speed hydraulic winch / high power hydraulic winch

custom built high speed hydraulic winch / high power hydraulic winch

China custom built high speed hydraulic winch / high power hydraulic winch supplier

Large Image :  custom built high speed hydraulic winch / high power hydraulic winch

Product Details:

Place of Origin: china
Brand Name: kemercn@hotmail.com
Certification: ISO9001
Model Number: AF series

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: case
Delivery Time: 3-20 days
Payment Terms: T/T or L/C
Supply Ability: on request
Detailed Product Description
Pull Force: 500-60,000kgs Rope Speed: 0-200m/min
Dimension: Custom Built Contact: Cathy
Skype: Kemercathy Email: Kemercn@hotmail.com
Cell: 008613486645746

hydraulic winch manufacturer, hydraulic winches, hoisting winch, marine winch, drilling rig winch, crane winch, power winch, hydraulic operated winch, dredger winch

Product description

We are the China-based manufacturer of hydraulic winch (hydraulic winch, hoisting winch, wireline winch, cargo winch, drilling rig winch, crane winch, marine winch, dredger winch, hydraulic winches, compact winch, free fall hydraulic winch) with more than 10 years experience in designing and manufacturing different types of hydraulic winches fro widely application.
We are the group company in China, the registered capacity is 6,000,000 and the factory area is about 6000sqm. Staffed with 150 employees, including 10 engineers.
The products are widely used in engineering machinery, ship-, petroleum-, mining industry, metallurgical machinery, light industry, agriculture, enviroment.
Now we are stepping into the international market, our products are being exported to Germany, USA, CANADA, ITALY, NETHERLAND, KOREAM, SINGAPORE, TURKEY, AUSTRALIA, INDIA, INDONESIA and others.
Specification of hydraulic winch:
1. Pull force of 1st layer: 1-100 ton
2. Rope speed: 0-200m/min
3. Option for the winch with groove or without groove

Description of hydraulic winch AF series

For the winch in the picture, it is our AF series hydraulic winch, which is widely used in ship crane, harbor, petroleum, drill machine, engineering machinery, geological exploration and construction machinery. It is the best choice for those situations which requires large power, high speed and high security.

Special Features:

1.Two-or three-stage planetary gearboxes, smooth operation and reasonable structure.
2.Normally closed friction type brake, high braking torque, safe and reliable operating.
3.Small volume, compact structure and high transmission efficiency.
4.Axial fixed or variable hydraulic motor with long life operating.
5.Mounting frame is available on request.
6.Balance valve, shuttle valve, limit switch and other accessories are also available on request.


Specification


For the folowing specification in the table, it is for your reference. We can also manufacture the winch with pull force up to 60,000kgs based on your requirements.

hydraulic winch manufacturer 1-60 ton
Model Pull Force (KN) Rope Speed (m/min) Diameter of rope (mm) Capacity of rope (m) Working pressures diff. (Mpa) Flow Rate (L/min)
1st layer toplayer
AF5700 5700 4500 60 16 107 25 160
AF7700 7700 6000 52 18 118 25 180
AF9600 9600 7500 43 20 118 25 180
AF12800 12800 9800 43 24 118 27 220
AF15000 15000 12800 39 24 110 25 220
AF18500 18500 14600 85.3 28 162 27 380
AF25000 25000 19500 48.1 30 162 27 380
AF30000 30000 23000 32 32 169 30 380
AF45000 45000 34700 32 42 169 30 380

hydraulic winch

Picture for reference:


custom built high speed hydraulic winch / high power hydraulic winch
Factory overview: factory overviewwinch productioncustom built high speed hydraulic winch / high power hydraulic winchpicture of winch

Package:

custom built high speed hydraulic winch / high power hydraulic winch



Contact Information

Contact: Cathy

Skype: kemercathy

Email: kemercn@hotmail.com

Tel: 0086-134 8664 5746

Contact Details
China KB Machinery Imp and Exp Co.,Ltd

Contact Person: Ms. Cathy Xu

Tel: 86-134-86645746

Fax: 86-574-86105326
