AF series high speed hydraulic winch (pull force: 1-100ton)

Place of Origin Ningbo, China
Brand Name
Certification ISO9001
Model Number AF series
Minimum Order Quantity 1 unit
Price negotiation
Packaging Details CASE
Delivery Time 20 days
Product Details
Pull Force 1-100 Ton Rope Speed 0-200m/min
Option With Or Wihtout Groove Material Forging
Contact Cathy Email
Leave a Message
Product Description

DOWNLOAD: AF series high speed hydraulic winch (pull force: 1-100ton) 0



China high quality hydraulic winch maufacturer


We are the China-based manufacturer of hydraulic winch (hydraulic winch, hoisting winch, wireline winch, cargo winch, drilling rig winch, crane winch, marine winch, dredger winch, hydraulic winches, compact winch, free fall hydraulic winch) with more than 10 years experience in designing and manufacturing different types of hydraulic winches fro widely application.
Company introduction
We are the group company in China, the registered capacity is 6,000,000 and the factory area is about 6000sqm. Staffed with 150 employees, including 10 engineers.
The products are widely used inengineering machinery, ship-, petroleum-, mining industry, metallurgical machinery, light industry, agriculture, enviroment.
Now we are stepping into the international market, our products are being exported toGermany, USA, CANADA, ITALY, NETHERLAND, KOREAM, SINGAPORE, TURKEY, AUSTRALIA, INDIA, INDONESIA and others.
Introduction of hydraulic winch AF series
AF series high speed hydraulic winch (pull force: 1-100ton) 1
For the winch in the picture, it is our AF series hydraulic winch, which is widely used in ship crane, harbor, petroleum, drill machine, engineering machinery, geological exploration and construction machinery. It is the best choice for those situations which requires large power, high speed and high security.
Special features of winch:
1.Two-or three-stage planetary gearboxes, smooth operation and reasonable structure.
2.Normally closed friction type brake, high braking torque, safe and reliable operating.
3.Small volume, compact structure and high transmission efficiency.
4.Axial fixed or variable hydraulic motor with long life operating.
5.Mounting frame is available on request.
6.Balance valve, shuttle valve, limit switch and other accessories are also available on request.
For the folowing specification in the table, it is for your reference. We can also manufacture the winch with pull force up to 60,000kgs based on your requirements.

Specification of hydraulic winch:

Model Pull Force (KN) Rope Speed (m/min) Diameter of rope (mm) Capacity of rope (m) Working pressures diff. (Mpa) Flow Rate (L/min)
1st layer top layer
AF5700 5700 4500 60 16 107 25 160
AF7700 7700 6000 52 18 118 25 180
AF9600 9600 7500 43 20 118 25 180
AF12800 12800 9800 43 24 118 27 220
AF15000 15000 12800 39 24 110 25 220
AF18500 18500 14600 85.3 28 162 27 380
AF25000 25000 19500 48.1 30 162 27 380
AF30000 30000 23000 32 32 169 30 380
AF45000 45000 34700 32 42 169 30 380

Note: the above specification of winch are only for your reference. We can also design and manufacture the winch based on your requirements for different applications.


Contact Information:

Contact: Cathy

Skype: kemercathy


Tel: 0086-134 8664 5746


Factory overview

hydraulic winch

AF series high speed hydraulic winch (pull force: 1-100ton) 3factory overviewwinch production

AF series high speed hydraulic winch (pull force: 1-100ton) 6picture of winchAF series high speed hydraulic winch (pull force: 1-100ton) 8
