hot seel crawler track assembly steel track undercarriage
| Place of Origin | Ningbo |
|---|---|
| Brand Name | kemercn@hotmail.com |
| Certification | ISO9001 |
| Model Number | KST series |
| Minimum Order Quantity | 1 set |
| Price | Negotiation |
| Packaging Details | pallet |
| Delivery Time | 3-20 days |
| Payment Terms | T/T or L/C |
| Supply Ability | on request |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Steel Track Undercarriage | Load Capacity | 1-100 Ton |
|---|---|---|---|
| Track Drive | Single Speed Or Dual Speed On Request |
Product Description
Steel Track undercarriage manufacturer
Steel track undercarriage, Steel track frame, steel track chassis, steel track system, steel crawlerundercarriage, steel tracked undercarriage, drilling rig steel track undercarriage, crusher steel trackundercarriage, excavator track undercarriage
We are an experienced company specialized in manufacturing steel track undercarriage and rubber track undercarriage. we make custom track systems for your mobility needs, and our track undercarriage can carry up to 50ton,and supporting dual-speed final drive and travel 0-7km/h at grades up to 60%.
Specification of track undercarriage:
1.Load capacity: 500kgs-50,000kgs
2.walking speed: 0-10km/hr
3.travel drive: dual speed final drive or single speed, Rexroth GFT gearbox
6.delivery time: 3-20 days
7.Custom built: we can design and manufacture track undercarriage according to your specificdimension requirements.
We are an experienced company specialized in manufacturing steel track undercarriage and rubber trackundercarriage. We make custom track systems for your mobility needs, and our track undercarriage cancarry up to 50ton, and supporting dual-speed final drive and travel 0-7km/h at grades up to 100%.
Application
Special design catered to customer specifications. With years of experience we can offer the track designflexibility, rapid response and solutions that are always highly effective.
For application on drilling rigs, excavators, crushers, cranes, aerial platform, etc. with high efficiency andadaption of vile working condition.
Customize Solution
We have many professional engineers devoting to design the track undercarriages to meet differentcustomers' requirements. With our years of experience, we can take your concept from prototype toproduction. We are committed to our goal of exceeding your expectations and requirements for quality,reliability, and on-time delivery.
Competitive Price
We can provide our track undercarriage with most competitive price, great quality and best service.
If you have any question or need any help, please feel free to contact with us. Our service team is ready toprovide best service for you.
Specification
For the following dimension and specification, it is just for your reference, we can also design andmanufacture the winch based on your requirements.ST-STEEL TRACK UNDERCARRIAGE
|
MODEL
|
Dinamic
capacity |
Static
capacity |
Weight
kg. |
Press.Bar
|
oil flow
L/min |
Torque
Nm to engine |
Grad.
|
Speed
km/h |
|
ST-3500
|
3500
|
4000
|
750
|
220
|
35
|
4723
|
65%
|
2/3.2
|
|
ST-6000
|
6000
|
7000
|
1350
|
220
|
55
|
8330
|
65%
|
2/3.7
|
|
ST-8000
|
8000
|
9500
|
1830
|
300
|
82
|
11700
|
65%
|
2.8/4.7
|
|
ST-10000
|
10000
|
11300
|
2350
|
350
|
100
|
14800
|
65%
|
3/5.1
|
|
ST-12000
|
12000
|
15000
|
2950
|
350
|
124
|
22500
|
65%
|
2.9/4.9
|
|
ST-15000
|
15000
|
18000
|
3300
|
350
|
140
|
24000
|
65%
|
3.2/5.5
|
|
ST-20000
|
20000
|
25000
|
4300
|
350
|
220
|
38000
|
65%
|
3.5/5.4
|
|
ST-30000
|
30000
|
37000
|
6500
|
330
|
260
|
59000
|
65%
|
2.5/4.6
|
|
ST-40000
|
40000
|
480000
|
7100
|
350
|
290
|
72800
|
65%
|
2.3/4.3
|
|
MODEL |
A
Length |
B
Center Distance |
C
Height |
D
Total Width |
E
Width of track shoe |
F
Height of Cross beam |
No. of
roller |
|
ST-3500
|
2030
|
1500 |
485
|
1800
|
300
|
225
|
4+4
|
|
ST-6000
|
2467
|
1950
|
549
|
1700
|
300-400
|
240
|
5+5
|
|
ST-8000
|
2783
|
2265
|
548
|
1800
|
400-450
|
255
|
8+8
|
|
ST-10000
|
3800
|
3200
|
600
|
1700
|
400-500
|
280
|
9+9
|
|
ST-12000
|
3282
|
2575
|
720
|
2000
|
400-600
|
345
|
9+9
|
|
ST-15000
|
3666
|
2923
|
753
|
2000
|
500-800
|
360
|
8+8
|
|
ST-20000
|
4065
|
3323
|
786
|
|
500-800
|
375
|
8+8
|
|
ST-30000
|
4530
|
3730
|
836
|
|
500-800
|
405
|
9+9
|
|
ST-40000
|
4888
|
4090
|
880
|
|
500-800
|
420
|
10+10
|
Picture of undercarriage for reference
