1-30 ton rubber crawler undercarriage (track undercarriage assembly)

  • 1-30 ton rubber crawler undercarriage (track undercarriage assembly)
  • 1-30 ton rubber crawler undercarriage (track undercarriage assembly)
  • 1-30 ton rubber crawler undercarriage (track undercarriage assembly)
  • 1-30 ton rubber crawler undercarriage (track undercarriage assembly)
  • 1-30 ton rubber crawler undercarriage (track undercarriage assembly)
  • 1-30 ton rubber crawler undercarriage (track undercarriage assembly)
Place of Origin Ningbo
Brand Name kemercn@hotmail.com
Certification ISO9001
Model Number KRT series
Minimum Order Quantity 1 unit
Price Negotiation
Packaging Details pallet
Delivery Time 3-20 days
Payment Terms T/T or L/C
Supply Ability on request

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Rubber Crawler Undercarriage Payload 500-30,000kgs
Application Crawler Excavator,drill Rig,Multipurpose,Construction Machinery Name Can Be Customized Size Undercarriage/rubber Track Chassis
Quality ISO9001 Certificate,100% Tested
Leave a Message
Product Description

1-30 ton rubber crawler undercarriage (track undercarriage assembly) 0

Rubber Track undercarriage manufacturer

Rubber track undercarriage, rubber track system, rubber track frame, rubber crawler undercarriage, rubber crawler chasis, rubbercrawler track undercarriage, drilling rig rubber track undercarriage, undercarriage assembly

Rubber track undercarriage, rubber track system, rubber track frame, rubber crawler undercarriage, rubber crawler chasis, rubbercrawler track undercarriage, drilling rig rubber track undercarriage, undercarriage assembly

Why to choose us?

We are the manufacturer and factory of rubber track undercarriage and steel track undercarriage. We have experienced engineers with more than 10 years' experience in design and manufacturing different types of undercarriage for drilling rig, crusher, shredder, etc.



We are an experienced company specialized in manufacturing steel track undercarriage and rubber track undercarriage. we make custom track systems for your mobility needs, and our track undercarriage can carry up to 50ton,and supporting dual-speed final drive and travel 0-7km/h at grades up to 60%.



Specification of track undercarriage:

1.Load capacity: 500kgs-50,000kgs
2.walking speed: 0-10km/hr
3.travel drive: dual speed final drive or single speed, Rexroth GFT gearbox
6.delivery time: 3-20 days

7.Custom built: we can design and manufacture track undercarriage according to your specificdimension requirements.





Application
Special design catered to customer specifications. With years of experience we can offer the track designflexibility, rapid response and solutions that are always highly effective.
For application on drilling rigs, excavators, crushers, cranes, aerial platform, etc. with high efficiency andadaption of vile working condition.
Customize Solution
We have many professional engineers devoting to design the track undercarriages to meet differentcustomers' requirements. With our years of experience, we can take your concept from prototype toproduction. We are committed to our goal of exceeding your expectations and requirements for quality,reliability, and on-time delivery.

Specification

For the following dimension and specification, it is just for your reference, we can also design andmanufacture the undercarriage based on your requirements.
RT-RUBBER TRACK UNDERCARRIAGE

rubber track undercarriage <font color=
MODEL
Dinamic
capacity
Static
capacity
Weight
kg.
Press.Bar
oil flow
L/min
Torque
Nm to
engine
Grad.
Speed
km/h
RT-1500
1200
1500
330
270
17
2000
65%
1.7
RT-2500
2500
3000
380
220
35
4723
65%
2/3.2
RT-3500
3500
4000
650
220
35
4723
65%
2/3.5
RT-5000
5000
6000
900
220
55
8330
65%
2/3.7
RT-6000
6000
7000
1280
220
55
8330
65%
2/3.7
RT-8000
8000
9500
1550
300
82
11700
65%
2.8/4.7
MODEL
A
Length
B
Center Distance
C
Height
D
Total Width
E
Width oftrack shoe
F
Height of Cross beam
No. of
roller
RT-1500
1420
1066
350
980
230
165
3+3
RT-2500
1850
1370
480
1220
250
245
4+4
RT-3500
1980
1511
500
1520
300
250
5+5
RT-5000
2500
1950
550
1800
350
265
6+6
RT-6000
2905
2355
550
1800
400
265
7+7
RT-8000
2950
2450
600
1800
400
310
7+7





FAQ

Q:Is your company a trader or manufacturer?

A:We are the manufacturer. We make steel track undercarriage and rubber track undercarriages.

Steel (2 ton to 120 ton),Rubber(0.5 to 10 ton).

Q:Can you supply customized service?

A:Yes,we can customize the undercarriage according to your demand.
And OEM Is also available.

Q:How's your products?

A:We have professional engineers and experienced team.And with many years experience in this field,our product are wildly welcomed by many customers.

Q:How is your price?

A:Our price is based on the quality,we give the competitive price to every customer!

Q:How is your after-sale Service?


A:We can give you one years after sales warranty,and an quality problem caused by manufacturing defects can be unconditionally interchanged into a new one.

Q: How to get customized service?

A: We need info as below:

1.Rubber or steel track undercarriage

2.Loading capacity(including the track undercarriage)

Or payload

3.Length

4.Width

5.Height

6.Travel speed

7.Climbing Capacity





Contact Information

high quality 8 ton steel track undercarriage for drilling rig 3



Picture of undercarriage
