rubber track undercarriage manufacturer rubber track system rubber crawler chassis
| Place of Origin | Ningbo |
|---|---|
| Brand Name | cathyhsu@foxmail.com |
| Certification | ISO9001 |
| Model Number | KRT series |
| Minimum Order Quantity | 1 set |
| Price | Negotiation |
| Packaging Details | pallet |
| Delivery Time | 3-20 days |
| Payment Terms | T/T or L/C |
| Supply Ability | on request |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Payload | 1-100 Ton | Type | Rubber Track Undercarriage |
|---|---|---|---|
| Application | Drilling Rig Track Undercarriage, Crusher Track Undercarriage, Etc. |
Product Description
Rubber Track undercarriage manufacturer
Rubber track undercarriage supplier
Rubber crawler undercarriage manufacturer
rubber track system manufacturer
Rubber track undercarriage, rubber track system, rubber track frame, rubber crawler undercarriage, rubber crawler chasis, rubbercrawler track undercarriage, drilling rig rubber track undercarriage, undercarriage assembly
We are an experienced company specialized in manufacturing steel track undercarriage and rubber track undercarriage. we make custom track systems for your mobility needs, and our track undercarriage can carry up to 50ton,and supporting dual-speed final drive and travel 0-7km/h at grades up to 60%.
Specification of track undercarriage:
1.Load capacity: 500kgs-50,000kgs
2.walking speed: 0-10km/hr
3.travel drive: dual speed final drive or single speed, Rexroth GFT gearbox
6.delivery time: 3-20 days
7.Custom built: we can design and manufacture track undercarriage according to your specificdimension requirements.
Application
Special design catered to customer specifications. With years of experience we can offer the track designflexibility, rapid response and solutions that are always highly effective.
For application on drilling rigs, excavators, crushers, cranes, aerial platform, etc. with high efficiency andadaption of vile working condition.
Customize Solution
We have many professional engineers devoting to design the track undercarriages to meet differentcustomers' requirements. With our years of experience, we can take your concept from prototype toproduction. We are committed to our goal of exceeding your expectations and requirements for quality,reliability, and on-time delivery.
Competitive Price
We can provide our track undercarriage with most competitive price, great quality and best service.
If you have any question or need any help, please feel free to contact with us. Our service team is ready toprovide best service for you.
Why to choose us:
1. professional technical support
we have experienced engineering teams offering best solution based on your application.
2. the main part of track drive gearbox is manufactured by our own factory
As we all know, the main part of track undercarriage is the track drive gearbox. We are also the manufacturer of planetary gearbox. We are more familiar with the performance of track drive gearbox and can suggest suitable track drive gearbox based on different load capacity.
3. custom design for length*width*height
4. test before delivery
Before delivery, we will do the test for the track undercarriage to check whether it is working fluently.
Detail Specification
For the following dimension and specification, it is just for your reference, we can also design andmanufacture the RUBBER TRACK UNDERCARRIAGE based on your requirements.
RT-RUBBER TRACK UNDERCARRIAGE
|
MODEL
|
Dinamic
capacity |
Static
capacity |
Weight
kg. |
Press.Bar
|
oil flow
L/min |
Torque
Nm to engine |
Grad.
|
Speed
km/h |
|
RT-1500
|
1200
|
1500
|
330
|
270
|
17
|
2000
|
65%
|
1.7
|
|
RT-2500
|
2500
|
3000
|
380
|
220
|
35
|
4723
|
65%
|
2/3.2
|
|
RT-3500
|
3500
|
4000
|
650
|
220
|
35
|
4723
|
65%
|
2/3.5
|
|
RT-5000
|
5000
|
6000
|
900
|
220
|
55
|
8330
|
65%
|
2/3.7
|
|
RT-6000
|
6000
|
7000
|
1280
|
220
|
55
|
8330
|
65%
|
2/3.7
|
|
RT-8000
|
8000
|
9500
|
1550
|
300
|
82
|
11700
|
65%
|
2.8/4.7
|
|
MODEL
|
A
Length |
B
Center Distance |
C
Height |
D
Total Width |
E
Width oftrack shoe |
F
Height of Cross beam |
No. of
roller |
|
RT-1500
|
1420
|
1066
|
350
|
980
|
230
|
165
|
3+3
|
|
RT-2500
|
1850
|
1370
|
480
|
1220
|
250
|
245
|
4+4
|
|
RT-3500
|
1980
|
1511
|
500
|
1520
|
300
|
250
|
5+5
|
|
RT-5000
|
2500
|
1950
|
550
|
1800
|
350
|
265
|
6+6
|
|
RT-6000
|
2905
|
2355
|
550
|
1800
|
400
|
265
|
7+7
|
|
RT-8000
|
2950
|
2450
|
600
|
1800
|
400
|
310
|
Picture for reference:
Factory Overview
FAQ
1. Are you the manufacturer or trader?
We are the manufacturer with more than 20 years experience engaged in designing and manufacturing of undercarriage.
2. How long is the delivery?
Usually it is 20 days for the production.
3. What's the warranty of your product?
We can offer you 12 months quality guarantee period after receipt of product.
4. Can you custom make the product?
Yes, all dimensions and specifications can be designed and made based on your requirements.
5. How to order?
To make sure the offered undercarriage is suitable for your application, please offer the following details:
1. Rubber or steel track undercarriage:
2. What is the payload of undercarriage:
Note: it is the weight of machine excluding the weight of undercarriage.
3. length of track undercarriage (mm):
4. width of each side of track undercarriage (mm):
5. height of track undercarriage (mm):
6. total width of track undercarriage (mm):
7. working flow rate per each side of undercarriage (L/min):
8. working pressure (MPa):
9. travelling speed (km/hr):
10. climbing capacity:
