wholesale industrial hydraulic winch small winch from china supplier

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xPull Force | 500-60,000kgs | Rope Speed | 0-200m/min |
---|---|---|---|
Dimension | Custom Built | Contact | Cathy |
Skype | Kemercathy | Cathyhsu@foxmail.com | |
+8613486645746 |

compact hydraulic winch for crane, hydraulic winch for drilling rig, wireline winch
For the winch in the picture, it is our BG series hydraulic winch, whichare widely used in overhead working truck, lorry mounted crane, drill machine, mirror crane, ship equipments and so on. It is the best choice for those situations that requires the narrow space and light weight.
Special Features
♦Floating type planetary gearbox, smooth operation and reasonable structure.
♦ Normally closed friction type brake, high braking torque, safe and reliable operating.
♦ Small volume, compact structure and high transmission efficiency.
♦ Long life Danfoss hydraulic orbit motor
♦ Mounting frame is available on request.
♦ Balance valve, shuttle valve, limit switch and other accessories are also available on request.
For the following specification, it is for your reference, we can also design and manufacture the winch with pull force up to 60 ton based on your requirements.
Model | W.L.L. 1st layer |
W.L.L. top layer |
Rope Speed | Rope diam. |
Capacity of Rope | Working Pressure | Max Supply Oil Flow |
kgf | kgf | m/min | mm | m | Mpa | L/min | |
BG500 | 500 | 380 | 63 | 6 | 67 | 14 | 40 |
BG800 | 800 | 680 | 54 | 8 | 53 | 14 | 50 |
BG1100 | 1100 | 870 | 41 | 8 | 53 | 14 | 50 |
BG1300 | 1300 | 1000 | 45 | 9 | 48 | 14 | 55 |
BG1500 | 1500 | 1200 | 42 | 10 | 60 | 21 | 55 |
BG2000 | 2000 | 1600 | 35 | 10 | 60 | 21 | 55 |
BG2500 | 2500 | 2000 | 52 | 12 | 52 | 21 | 100 |
BG2600 | 2600 | 2000 | 54 | 12 | 76 | 21 | 100 |
BG3200 | 3200 | 2500 | 44 | 14 | 66 | 21 | 100 |
BG3600 | 3600 | 2800 | 40 | 14 | 66 | 21 | 100 |
BG4500 | 4500 | 3500 | 36 | 15 | 89 | 21 | 110 |
BG5700 | 5700 | 4500 | 26 | 16 | 102 | 21 | 120 |
For above specification, it is just for your reference. We can offer winch with pull force 1-100 ton.
