rubber track undercarriage manufacturer from China
| Place of Origin | NINGBO, CHINA |
|---|---|
| Brand Name | cathyhsu@foxmail.com |
| Certification | ISO9001 |
| Model Number | RT series rubber track undercarriage |
| Minimum Order Quantity | 1 set |
| Price | 2000-10000 |
| Packaging Details | PALLET |
| Delivery Time | 20-50 days |
| Payment Terms | L/C, T/T |
| Supply Ability | contact me: cathyhsu@foxmail.com |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Rubber Track Undercarriage | Dimension | Custom Built For Length*width*height |
|---|---|---|---|
| Payload | 500-30,000kgs | Track Drive | Doosan, Jeil, Rexroth Final Drive Gearbox |
Product Description
Rubber track undercarriage manufacturer from China
Rubber track undercarriage supplier
Rubber track undercarriage factory
We are the manufacturer of track undercarriage from China. We can offer rubber track undercarriage with payload 500-30000kgs and steel track undercarriage with payload 500-100000kgs.
The dimension (length*width*height) of track undercarriage can be designed based on the special requirements of each customers.
The track drive gearbox of track undercarriage can be Eaton JMV series final drive gearbox, Rexroth GFT track drive gearbox, Doosan TM series track drive gearbox. Or you can choose our own brand final drive gearbox to lower the cost.
Compared with other manufacturer of track undercarriage, we are also the manufacturer of hydraulic products, such as hydraulic motor, hydraulic winch, track drive gearbox and planetary gearbox. We are more familiar with the perofrmance of track drive gearbox so that we can suggest the suitable track drive gearbox for track undercarriage.
We can also offer our own brand dual speed track drive gearbox and single speed track drive gearbox.
For the dual speed final drive gearbox, it is similar to the structure of Eaton final drive gearbox Doosan final drive.
For the single speed final drive gearbox, it is made up of planetary gearbox and orbital motor; planetary gearbox with GM motor or planetary gearbox with bent axis hydraulic motor (interchanged with Rexroth GFT series track drive gearbox with A2FE hydraulic motor). We can suggest one of them for the undercarriage based on different requirements of each customer's.
How to choose right track undercarriage for your application?
To make sure that the undercarriage we suggested is suitable for your application, please offer the following detail requirements:
1. Rubber or steel track undercarriage:
2. What is the payload of undercarriage:
Note: it is the weight of machine excluding the weight of undercarriage.
3. length of track undercarriage (mm):
4. width of each side of track undercarriage (mm):
5. height of track undercarriage (mm):
6. total width of track undercarriage (mm):
7. working flow rate per each side of undercarriage (L/min):
8. working pressure (MPa):
9. travelling speed (km/hr):
10. climbing capacity:
Note: for the payload we mentioned, it is the weight carried by the track undercarriage. It is not the complete weight of your machine including the weight of track undercarriage. Please specify it clearly so that we can offer suitable final drive gearbox for the undercarriage with competitive price.
Specification of track undercarriage for reference:
For the following dimension and specification, it is just for your reference, we can also design andmanufacture the RUBBER TRACK UNDERCARRIAGE based on your requirements.
RT-RUBBER TRACK UNDERCARRIAGE
|
MODEL
|
Dinamic
capacity |
Static
capacity |
Weight
kg. |
Press.Bar
|
oil flow
L/min |
Torque
Nm to engine |
Grad.
|
Speed
km/h |
|
RT-1500
|
1200
|
1500
|
330
|
270
|
17
|
2000
|
65%
|
1.7
|
|
RT-2500
|
2500
|
3000
|
380
|
220
|
35
|
4723
|
65%
|
2/3.2
|
|
RT-3500
|
3500
|
4000
|
650
|
220
|
35
|
4723
|
65%
|
2/3.5
|
|
RT-5000
|
5000
|
6000
|
900
|
220
|
55
|
8330
|
65%
|
2/3.7
|
|
RT-6000
|
6000
|
7000
|
1280
|
220
|
55
|
8330
|
65%
|
2/3.7
|
|
RT-8000
|
8000
|
9500
|
1550
|
300
|
82
|
11700
|
65%
|
2.8/4.7
|
|
MODEL
|
A
Length |
B
Center Distance |
C
Height |
D
Total Width |
E
Width of track shoe |
F
Height of Cross beam |
No. of
roller |
|
RT-1500
|
1420
|
1066
|
350
|
980
|
230
|
165
|
3+3
|
|
RT-2500
|
1850
|
1370
|
480
|
1220
|
250
|
245
|
4+4
|
|
RT-3500
|
1980
|
1511
|
500
|
1520
|
300
|
250
|
5+5
|
|
RT-5000
|
2500
|
1950
|
550
|
1800
|
350
|
265
|
6+6
|
|
RT-6000
|
2905
|
2355
|
550
|
1800
|
400
|
265
|
7+7
|
|
RT-8000
|
2950
|
2450
|
600
|
1800
|
400
|
310
|
7+7
|
Application of track undercarriage
drilling machines (core drill, horizontal directional drilling rig, belt engineering drill, and engineering rig), engineering machines, mining, colliery, agricultural and gardening machines.
Detail of undercarriage:
Guard cover to protect the track drive gearbox (if required)
Picture of undercarriage for reference
